Allen Bradley 2711P-T6C8A

Njengomthengisi oqeqeshiweyo, i-Feimu Technology ikunika le Allen Bradley 2711P-T6C8A.Le yiPanelView Plus 400 series terminal, sidlula inkqubo yokuhlola engqongqo ukuqinisekisa ukuba isixhobo ngasinye esithunyelwe ezandleni zakho sisebenza ngokupheleleyo kwaye sinyanisekile kumbala. Ukuba unazo naziphi na iimfuno, nceda uzive ukhululekile ukubuza. Sizimisele ukukunika iimveliso ezikumgangatho ophezulu.

Thumela uMbuzo

Ingcaciso yeMveliso

I-Feimu Technology, njengomthengisi oqeqeshiweyo, ibandakanyeke ngokunzulu kwi-industrial automation field ngaphezulu kweminyaka engama-20, igxile ekuboneleleni ngezixhobo ezikumgangatho ophezulu zolawulo lwamashishini. I-Allen Bradley 2711P-T6C8A esiyiphehleleleyo yitheminali yokuchukumisa yakudala yePanelView Plus 600 series. Nangona inoyilo oludityanisiweyo oluyi-5.7-intshi, yenza eyona njongo iphambili yokwenza ukuba abaqhubi banxibelelane nesixhobo. Ngaphandle kwemisebenzi entsonkothileyo, yenza ulawulo olucacileyo lwemeko yokusebenza yesixhobo kunye nokujongwa kwexesha langempela ledatha yangaphakathi. Nokuba yeyokudityaniswa kwesixhobo esitsha okanye ukuphuculwa kwesixhobo esidala, lukhetho olukhethayo oluguquguqukayo noluhlala ixesha elide. Kuyo yonke le nkqubo, uhlolo olungqongqo lwekhwalithi luyenziwa ukuze kuqinisekiswe ukuba isixhobo ngasinye sihlangabezana nemigangatho yoshishino.

Ukucaciswa kweMveliso

Igama lemveliso	Allen Bradley 2711P-T6C8A
Bonisa	5.7-intshi Umbala TFT
Isigqibo	320 x 240 (QVGA)
Uhlobo lokuchukumisa	Ukuxhathisa
Unxibelelwano	I-Ethernet / RS-232
Ukunikezwa Amandla	18 - 32 V DC
Isoftware	FactoryTalk Jonga ME

Ukusebenza okungundoqo

I-Allen Bradley 2711P-T6C8A ixhotyiswe ngeFactoryTalk View ME isoftware ezinikeleyo, enesantya sokusebenza esikhawulezayo kunye nokutshintsha kwesikrini ngaphandle kokushiyeka. Oku kuyisombulula ngokupheleleyo ingxaki yokuphendula ngokucothayo kwiitheminali zokucofa kwimiba yoshishino. Inokuhambelana okunamandla kakhulu, ayipheleli nje ekudityanisweni komthungo kunye nezixhobo ze-PLC zikaRockwell, kodwa inxibelelana ngokulula nezinye izixhobo zeshishini. Inokuguquguquka okubanzi kwaye ingasetyenziswa ngaphandle kolungiso olongezelelweyo. Kwangaxeshanye, isixhobo sinamandla kakhulu okuthintela ukuphazamiseka. Inokugcina ukusebenza okuzinzileyo naxa ijongene nokuguquguquka kwegridi yamandla okubangelwa kukuqaliswa kwezixhobo zamandla amakhulu kumzi-mveliso, ngaphandle kokufumana ukuphazamiseka kwenkqubo okanye ukuqhwanyaza kwesikrini, ngokufanelekileyo iqinisekisa ukusebenza okuqhubekayo komgca wemveliso kunye nokukhusela ukusebenza kakuhle kwemveliso yomzi-mveliso. Sinikezela ngokungqongqo iimveliso ezitsha kwaye siyala izinto ezihlaziyiweyo. Siqinisekisa uMgangatho ovela kumthombo kunye nokuphelisa iingxaki eziqhelekileyo ezifana nezikrini ezimnyama kunye nokungasebenzi kakuhle, ukuvumela wonke umthengi ukuba asebenzise izixhobo ezizinzileyo nezithembekileyo zoshishino.

Iimbalasane zeMveliso

Eyona nto iphawulekayo ye-Allen Bradley 2711P-T6C8A kukudibanisa kwayo ukusebenza kakuhle kunye nokulula kunye nokuzinza kunye nokuqina. Inesantya esikhawulezayo sokuqalisa kwaye inokungena ngokukhawuleza ujongano lokusebenza emva kokuba ilayitiwe. Xa kuthelekiswa neetheminali zomnxeba ezindala, inciphisa kakhulu ixesha lokusebenza kwindawo kwaye iphucula ukusebenza kakuhle. Isikrini senziwe ngombala oqaqambileyo we-TFT wezinto. Nangona kwindawo yokusebenzela ekhanyiswe kakuhle, akukho mfuneko yokuthintela ukukhanya ukujonga ngokucacileyo isicatshulwa sesikrini kunye nedatha. Ubulula bokusebenza buphuculwe kakhulu.

Isixhobo samkela uyilo lokuthintela oluchasayo kwaye luxhasa ukusebenza ngesandla esingenanto okanye iiglavu, ezihlangabezana neemfuno zokusetyenziswa zabaqhubi bendawo yoshishino. Ukubamba kubuthathaka, kwaye ukubamba ukukhanya kunokuthumela ngokuchanekileyo imiyalelo. Ngelo xesha, izixhobo zinesakhiwo esincinci, sihambelana neekhabhinethi zokulawula i-Factory ye-industrial, kulula ukuyifaka, kwaye ayifuni ukuguqulwa okongeziweyo kwekhabhinethi, ngaloo ndlela ukunciphisa iindleko zokufakela kunye nobunzima bokwakha.

Iiparamitha ezineenkcukacha

I-Allen Bradley 2711P-T6C8A ibonisa ulungelelwaniso oluchanekileyo lweparameter ehlangabezana ngokuchanekileyo neemfuno zoshishino. Isikrini sinombala we-5.7-intshi ye-TFT yesikrini kunye nesisombululo se-320 × 240 (QVGA), ebonelela ngomboniso ocacileyo kunye neenkcukacha. Uhlobo lokubamba luxhathisa, luqinisekisa ukusebenza okuchanekileyo. Ixhasa iindlela ezimbini zonxibelelwano: i-Ethernet kunye ne-RS-232, kunye nokuhanjiswa kwedatha egudileyo. Ubonelelo lwamandla yi-18-32V DC, iyahambelana neenkcukacha zobonelelo lwamandla ezifanayo kwiindawo zemizi-mveliso, kwaye akukho nikezelo lombane longeziweyo olunikezelweyo olufunekayo, nto leyo eyenza ukuba isebenze kakhulu.

Izatifikethi zethu

Njenge-terminal interface yomsebenzisi kwi-PanelView Plus 600 series, izixhobo zethu zinenkqubo epheleleyo yoqinisekiso lwamazwe ngamazwe kunye nesiqinisekiso se-CE. Ihambelana neemfuno zokhuseleko, impilo kunye nokusingqongileyo kwe-EU, isatifikethi se-UL, isatifikethi se-c-UL-us sihlangabezana neemfuno zaseKhanada nase-United States. Ikwabambe umgangatho wokhuseleko lweCSA kwimarike yaseKhanada.

UQinisekiso lwezoThutho kunye nezinto eziluncedo kwiNkampani

ITekhnoloji yeFeimu, njengoMboneleli oqeqeshiweyo, inendlu enkulu yokugcina izinto ekrelekrele. U-Allen Bradley 2711P-T6C8A usesitokhweni kwaye uyafumaneka ukuze unikezelwe ngokukhawuleza. Inokusabela ngokukhawuleza kwiimfuno zabathengi kwaye isombulule ingxaki yokuthengwa kwezixhobo ezingxamisekileyo. Samkela ukupakishwa kokhuselo olunamanqanaba amaninzi. Okokuqala, isongelwe kwingxowa ekhethekileyo ye-anti-static, emva koko igqunywe ngongqimba olungqindilili lwefilimu yeqamza. Uluhlu lwangaphandle luxhotyiswe ngebhokisi yekhadibhodi eyomeleleyo kunye ne-foam ye-cushion. Yonke le nkqubo ikhuselwe. Nokuba ithuthwa isiwe eMelika, eYurophu okanye kweminye imimandla, izixhobo zinokuqinisekiswa ukuba zilungile kwaye zihanjiswa kwimeko efanayo nentsha.

Ixabiso lemveliso liyafikeleleka, kwaye libiza kakhulu. Siwacima amakhonkco aphakathi kwaye sibonelela abathengi ngemigangatho ephezulu yokulawula iitheminali kwimizi-mveliso ngamaxabiso akhuphisana kakhulu. Kwangaxeshanye, sineqela lokuhlola ubuchwephesha. Zonke izixhobo ezikhutshwe kwifektri zivavanywa ngamandla, kwaye nganye ihlolwe ukubonisa isikrini, ukuphendula ngokuchukumisa, ukugudisa unxibelelwano kunye nezinye izinto zokusebenza ukuqinisekisa ukuba izixhobo zilungile kwaye zisebenziseka. Ukongeza, sixhotyiswe ngeqela lenkxaso yobugcisa beeyure ezingama-24, ukubonelela ngokubonisana ngokukhetha, isikhokelo emva kokuthengisa kunye nezinye iinkonzo ezibanzi. Ngokuthembela kwii-giants zentsebenziswano zasekhaya kunye nezangaphandle, sifezekisa ukuhanjiswa okukhawulezileyo kwehlabathi, okwenza kube lula kubathengi ukuthenga nokusebenzisa ngoxolo lwengqondo.

Ukwahlulwahlulwa kweNani leModeli

Ukuqonda inombolo yemodeli kukunceda uqinisekise iinkcukacha kwaye ukhethe imveliso echanekileyo.

2711P:PanelView Plus series
T:Isikrini esibanjwayo
6:5.7-intshi ukubonisa
C:Umboniso wombala
8:8 amaqhosha omsebenzi
A:Unxibelelwano olusemgangathweni (i-Ethernet + RS-232)

PanelView Plus 600 Series Uthelekiso

I-PanelView Plus 600 series ineemodeli ezininzi ezinomboniso ohlukeneyo kunye neenketho zokungena. Olu thelekiso lukunceda ukuba ukhethe imodeli echanekileyo.

Umzekelo	Bonisa ubukhulu	Isigqibo	Uhlobo Longeniso	Amaqhosha oMsebenzi
2711P-T6C8A	5.7 intshi	320 x 240	Isikrini esibanjwayo	8 izitshixo
2711P-T6C20A	5.7 intshi	320 x 240	Isikrini esibanjwayo	20 izitshixo
2711P-K6C8A	5.7 intshi	320 x 240	Iphedi yezitshixo kuphela	8 izitshixo
2711P-B6C8A	5.7 intshi	320 x 240	Isikrini sokuchukumisa + Iphedi yezitshixo	8 izitshixo

Ukusekwa koNxibelelwano - i-Ethernet kunye ne-RS-232

I-2711P-T6C8A isekela i-Ethernet kunye ne-RS-232 unxibelelwano. Izibuko ngalinye lisebenza ngenjongo eyahlukileyo.

I-I-I-Ethernet port:

Isetyenziselwa ukuqhagamshela kwii-PLC zanamhlanje (CompactLogix, ControlLogix).
Ixhasa i-EtherNet/IP protocol.
Isantya: 10/100 Mbps auto-thethwano.
Isetyenziselwa ukukhuphela inkqubo kunye notshintshiselwano lwedatha ye-HMI-PLC.

RS-232 izibuko:

Isetyenziselwa ukudibanisa kwii-PLC ezindala (i-SLC 500, i-PLC-5).
Ixhasa iprotocol yeDF1.
Umdibaniso: Umgangatho we-9-pin D-sub.
Izinga le-Baud: Luqwalaselwe (ukuya kuthi ga kwi-115.2 kbps).

Amanyathelo okuseta asisiseko:

Vula iFactoryTalk View Studio.
Yenza isicelo esitsha sePanelView Plus.
Khetha umqhubi wonxibelelwano (EtherNet/IP okanye RS-232 DF1).
Cwangcisa idilesi ye-IP (ye-Ethernet) okanye izinga le-baud (ye-RS-232).
Yenza iithegi ezibonisa imaphu kwidilesi yePLC.
Khuphela isicelo kwi-HMI.

Ubume be-LED kunye nokuJonga ingxaki

I-2711P-T6C8A inezikhombisi ze-LED kwiphaneli yangaphambili. Ezi zibonelela ngolwazi lwemeko yangoku.

I-LED	Ubume	Intsingiselo	Isenzo
PWR	Luhlaza	Iyunithi inikwe amandla kwaye isebenza ngokuqhelekileyo.	Akukho ntshukumo ifunekayo.
PWR	Cimile	Akukho mandla kwiyunithi.	Jonga i-24V DC amandla. Jonga iingcingo.
COMM	Luhlaza	Unxibelelwano luyasebenza.	Akukho ntshukumo ifunekayo.
COMM	Cimile	Akukho nxibelelwano.	Jonga intambo. Jonga useto lwePLC. Jonga idilesi ye-IP.
Impazamo	Bomvu	Impazamo yeyunithi. I-Hardware okanye impazamo yesoftware.	Jonga ubumbeko. Umjikelo wamandla. Faka enye indawo ukuba ibomvu ihlala.

UQiniso loBunyani

Allen Bradley 2711P-T6C8A HMIs ziqhele ukwenziwa umgunyathi. Sebenzisa olu vavanyo ukuqinisekisa ubunyani.

Umbala wephaneli yangaphambili:Iiyunithi zokwenyani zinombala othile omnyama ongwevu ohambelana nosapho lwePanelView Plus. Izinto zomgunyathi zidla ngokuba nomthunzi owahlukileyo.
Umgangatho weleyibhile:Iileyibhile zokwenyani zinokushicilelwa okusisigxina kunye nenombolo yemodeli 2711P-T6C8A ibonakala ngokucacileyo. Iileyibhile zomgunyathi zihlala zinombhalo omfiliba okanye amaxolo emiphethweni.
Umgangatho wesikrini:Izikrini zokwenyani ziqaqambile kwaye zicacile. Izikrini zomgunyathi zihlala zimfiliba okanye zinokuqaqamba okungalinganiyo.
I-I-I-Ethernet port:Izibuko ze-Ethernet zokwenyani zinezikhuselo zentsimbi. Izinto zomgunyathi zihlala zisebenzisa izibuko zeplastiki.
Chukumisa impendulo:Izikrini zokwenene zokuthintela ziyaphendula kwaye zichanekile. Izikrini zomgunyathi zihlala zisemva okanye zineendawo ezifileyo.
Ubunzima bemodyuli:I-Genuine 2711P-T6C8A inobunzima obumalunga ne-0.9 kg. Iinkohliso zihlala zivakala lula.
