Allen Bradley 1769-IA16

I-Feimu Technology, njengomthengisi oqeqeshiweyo, igxile ekuboneleleni ngamacandelo omatshini wokwenza izinto. Kubalawuli be-Factory CompactLogix, uye wasungula imodyuli ye-digital ye-Allen Bradley 1769-IA16, eyenzelwe ngokukodwa iimeko ezifuna i-digital inputs ye-16 kunye nokugcina indawo ye-rack. Iyinxalenye efanelekileyo yeadaptha yezixhobo zokulawula ezincinci kunye neziphakathi. Le mveliso yimodyuli yokuqala ka-Allen Bradley. Umsebenzi wayo oyintloko kukuguqula izibonakaliso ezivela kwi-site switch kunye ne-sensor kulwimi umlawuli we-PLC onokuluqonda, ukuhlangabezana neemfuno zezixhobo zokulawula ezincinci kunye neziphakathi.

Uyilo lwesakhiwo esibambeneyo

Uyilo lwangaphakathi lwesakhiwo sika-Allen Bradley 1769-IA16 lunengqiqo. Uyilo lwebhodi yesekethe lucocekile, amacandelo e-elektroniki acwangciswe ngocwangco, i-solder joints are thick and shiny, kunye nokuzinza kuyabonakala. Kuyaqinisekisa ngakumbi ukusebenzisa. Isixhobo sixhotyiswe nge-classical 1761 bus interface ezantsi, kunye noyilo lwepin yegolide ejiyileyo, enokuqinisekisa ngokufanelekileyo unxibelelwano oluhle kunye nephaneli yangasemva, ukunqanda ukusilela konxibelelwano okubangelwa yi-oxidation, kunye nokunciphisa iimpazamo ezinokubakho.

U-Allen Bradley mncinci ngokomlinganiselo, kuphela ububanzi besithuba esinye. Ukuyifakela kwikhabhinethi yolawulo kunokonga kakhulu indawo, ukwenza i-wiring ibe lula ngakumbi, kwaye wenze ukwakheka kwangaphakathi kwekhabhinethi yolawulo kucoceke ngakumbi, kuthintelwe ukuxinana kunye nokuphazamiseka. Iimveliso zethu ezibonelelweyo zonke zikumgangatho omtsha kraca, zilawula ngokungqongqo uMgangatho, zisusa iingxaki ezahlukeneyo zezinto ezihlaziyiweyo kwimvelaphi, kunye nokuqinisekisa ukusebenza okuzinzileyo kwexesha elide.

Ukuchasana nokuphazamiseka ngaphandle kokulibazisa

I-Allen Bradley 1769-IA16 ixhasa i-120V ye-AC ye-input signals kwaye inamandla kakhulu okumelana nokuphazamiseka. Iyakwazi ukuziqhelanisa nommandla oqinileyo wokuphazamiseka kombane ojikeleze iingcingo zesiza sefektri, ukwahlula ngokuchanekileyo phakathi kweempawu zangempela kunye neempawu zokuphazamiseka, kwaye aziyi kuxela ngobuxoki imiqondiso kumlawuli, iqinisekisa ukuchaneka kokulawulwa kwezixhobo. Kwangaxeshanye, isantya sokuphendula imodyuli sikhawuleza kakhulu. Emva kokuba i-on / off switch ivaliwe kwisayithi, umlawuli unokufumana isignali ngokukhawuleza, phantse akukho kulibaziseka.

Le mpendulo ekhawulezayo iqinisekisa ukuba izixhobo ziyakwazi ukusabela ngokukhawuleza, ngokufanelekileyo ukuphepha iingozi zokhuseleko ezibangelwa ukulibaziseka komqondiso. Ilungele iimeko ezahlukeneyo zamashishini amancinci naphakathi aneemfuno eziphezulu zovakalelo lweempawu, kwaye iyahambelana neekhabhathi zolawulo lwefektri. Ukufakela kukulungele, akukho kuguqulwa okongeziweyo okufunekayo, kwaye kunokunciphisa iindleko zokwakha.

Ukuqhawula ngokulula kunye nokudibanisa, ukulungisa iingxaki ngokulula

Olona phawu lunomtsalane lwe-Allen Bradley 1769-IA16 ziibhloko ze-terminal ezinokususwa. Xa ubuyisela imodyuli, khupha nje ibhloko ye-terminal, susa imodyuli endala, faka imodyuli entsha, kwaye ulungise kwakhona ibhloko ye-terminal. Ukutshintshwa kunokugqitywa kwimizuzwana embalwa, ukunciphisa kakhulu ixesha lokunciphisa izixhobo kunye nokuphucula ukusebenza kakuhle.

Ukongeza, iimodyuli zixhotyiswe ngezibane zesikhombisi se-LED. Indawo nganye yokufaka ihambelana nokukhanya kwesalathisi. Xa kukho igalelo lesignali, ukukhanya kwesalathisi kuya kuvula. Ngexesha lokusombulula ingxaki, akukho msebenzi onzima ofunekayo. Ngokujonga nje izibane zesalathisi, ingxaki inokufumaneka ngokukhawuleza, ukunciphisa kakhulu ubunzima bokusombulula ingxaki kunye nokugcina iindleko zabasebenzi.

FAQ

Yeyiphi inkqubo imodyuli esetyenziswayo?

Uthotho lwe-Allen-Bradley 1769 Compact I/O™ lusetyenziswa ikakhulu kwinkqubo yolawulo lweCompactLogix™ kwaye lunokusetyenziswa ngokubambisana neMicroLogix 1500 inkqubo.

Adityaniswa njani amanqaku ali-16 emodyuli?

Amanqaku e-16 egalelo aqulunqwe njengeqela elihlukeneyo kwaye abelane ngokudibanisa kwangaphakathi okuqhelekileyo, onke amanqaku okufaka axhunyiwe kwi-terminal efanayo (COM).

Ngaba inokusebenza ngokuzimeleyo?

Hayi. Ayinayo i-CPU kwaye kufuneka ifakwe kwi-backplane ye-CompactLogix (efana ne-1769-L30ER, njl.) okanye inkqubo ye-MicroLogix 1500 kwaye inxibelelane nomlawuli ngebhasi ye-backplane.

Ngaba ibhloko ye-terminal (RTB) ingaplagwa okanye ikhutshwe ngelixa ivuliwe?

Ukutshintshana okushushu kwemodyuli kuyaxhaswa. Kucetyiswa ukuba uqhawule amandla enkqubo kunye namandla akwisiza phambi kokususa ibhloko yeterminal okanye imodyuli. Ibhloko yeterminal (RTB) ilungiswa ngezikrufu ezibini phezulu nasezantsi. Xa utshintsha imodyuli, khulula ngokulula izikrufu kwaye uyikhuphe ngaphandle, akukho rewiring efunekayo.

Thenga ngokuLula kabini

I-Allen Bradley yeyokwakhiwa eyomeleleyo kwaye ayifuni ukulungiswa okuntsonkothileyo yonke imihla. Qaphela nje ukukhusela iifayili zentsimbi ekuweleni kwiibhloko ze-terminal kwaye zibangele isiphaluka esifutshane. Luvuthe rhoqo uthuli ukuze lucoceke. Kwimeko yokungasebenzi kakuhle, kubangelwa ikakhulu kwibhloko ye-terminal evuthayo okanye i-optocoupler yonakaliswe. Ungathenga ibhloko ye-terminal ngokwahlukileyo ukuze utshintshe, ngaphandle kokulahla yonke imodyuli, ukunciphisa ngokufanelekileyo iindleko zokugcinwa. Qaphela ukuba ungagobi izikhonkwane ezisezantsi xa uplaga okanye ukhulula, kwaye ungaze uchukumise iindawo eziqhubayo ngokuthe ngqo ngezandla zakho ukuthintela i-oxidation yezikhonkwane zegolide ngokubila ezandleni zakho.

I-Feimu Technology, njengomthengisi onamandla, inenkqubo epheleleyo yolawulo lwempahla. I-Allen Bradley 1769-IA16 ikwi-Stock kwaye iyafumaneka ukubonelela ngokukhawuleza, ukuphendula ngokukhawuleza kwiimfuno zokuthenga ezingxamisekileyo zabathengi. Imveliso ibonelela ngeXabiso elilungileyo kunye neendleko eziphezulu zokuSebenza. Sibambelela kumaxabiso afanelekileyo, siphelise amakhonkco aphakathi, kwaye sibonelela ngeemveliso ezikumgangatho ophezulu ngamaxabiso akhuphisana kakhulu.
