Allen Bradley 1785 L46C15

Ayiyiyo yonke imigca yemveliso efuna uqwalaselo oluphezulu lwe-100K. Into ebalulekileyo yanele. I-Feimu Technology, njengomboneleli okumgangatho ophezulu onamava abanzi kuphuculo lolawulo lwemizi-mveliso, iyile le Allen Bradley 1785 L46C15 ilungiselelwe iinkqubo eziphakathi.

Ngememori ye-48K, inokusingatha i-logic enzima, kunye neengongoma ze-2048 ze-I / O zigubungela imigca emininzi yokuvelisa; ine-ControlNet 1.5 interface eyakhelwe ngaphakathi, i-5Mbps yonxibelelwano olucacileyo, kunye ne-0.5ms yokuskena ngesantya esiphezulu; ineempawu zokukhusela inkumbulo ukukhusela iinkqubo eziphambili ukuba zingalungiswa okanye zilahleke. Izibuko ezimbini ze-BNC ezingafunekiyo zitshintshela ngokuzenzekelayo, nto leyo ilunge kanye ekuphuculeni imigca yemveliso ephakathi kukutya, ukupakishwa, kunye namashishini amalaphu.

Iinkcazo zobuGcisa

Izinto eziluncedo ezingundoqo kunye namanqaku okuthengisa

1. I-PLC-5 i-Platform yokulawula eZinzile kwaye ethembekileyo

I-Allen Bradley 1785 L46C15 ithatha i-architecture ye-PLC-5 evuthiweyo, eye yaqinisekiswa kwiindawo zoshishino ixesha elide kwaye ilungele ukusebenza ngokuqhubekayo kwezixhobo ezizenzekelayo.

Izinto eziluncedo:

Uzinzo oluphezulu lolawulo

Ukuziqhelanisa okunamandla kwiindawo zoshishino

Inkxaso yokusebenza kwexesha elide kunye nokugcinwa

2. Ifanelekile kwiPLC-5 System Maintenance

Kwiifektri ezisebenzisa i-PLC-5:

Akukho mfuneko yokutshintsha yonke inkqubo yolawulo

Gcina ingqiqo yenkqubo yokuqala

Ukunciphisa iindleko zokuphucula izixhobo

Nciphisa ixesha lokuphumla ukulungiselela ukulungiswa

3. Ixhasa iMisebenzi yoLawulo lwezoShishino oluNgxaki

Ifanelekile:

I-Multi-point I/O ulawulo

Ulawulo lwe-interlock lwezixhobo

Ulawulo lwenkqubo yokuvelisa ngokuzenzekela

Ukwanelisa iimfuno zolawulo lwemisebenzi yoshishino oluphakathi.

Inkqubo yofakelo

Inkqubo yokuqinisekisa:

Qinisekisa i-PLC - isakhelo se-5, imodyuli yokunikezelwa kwamandla, ukulungiswa kwe-I / O kunye nenethiwekhi yonxibelelwano kunye ne-1785 L46C15 ehambelanayo.

Ukusebenza kwamandla:

Vala inkqubo yolawulo lonikezelo lwamandla, qinisekisa izixhobo kwimeko ekhuselekileyo.

Ufakelo lwemodyuli:

Faka imodyuli yeprosesa kwi-slot ehambelanayo ye-rack ye-PLC-5 kwaye uqinisekise ukuba ixhunyiwe ngokukhuselekileyo kwi-backplane.

Unxibelelwano lonxibelelwano:

Qhagamshela i-DH + okanye iRemote I/O yonxibelelwano kwaye ujonge ukuba uqhagamshelo luchanekile.

Amandla eSistim avuliwe:

Vula amandla, khangela ukuba isalathisi se-CPU siqhelekileyo, akukho alarm ephosakeleyo.

Ubumbeko lwesicelo:

Ukusebenzisa i-RSLogix 5 eqhagamshelwe kwiprosesa, layisha / khuphela inkqubo ye-PLC, kwaye usete iiparitha ezihambelanayo zonxibelelwano.

Qhuba uvavanyo:

Jonga ubume be-CPU esebenzayo, impendulo ye-I/O kunye nomsebenzi wokulawula isixhobo ukuze uqinisekise ukuba inkqubo isebenza ngokuqhelekileyo.

Ubume bangaphakathi

Allen Bradley 178540 L46C15 PLC-5/c15 imodyuli yeprosesa ikakhulu yenziwe ngala malungu alandelayo:

Iyunithi yokucubungula i-CPU

Inoxanduva lokuqhuba inkqubo ye-PLC, ukusebenza ngengqiqo kunye nemisebenzi yokulawula.

Iyunithi yokugcina

Isetyenziselwa ukugcina iinkqubo zomsebenzisi, amaphepha edatha kunye neeparitha zenkqubo. Imodyuli yonxibelelwano

Uxanduva lwe-DH +, i-I / O ekude kunye nolunye unxibelelwano lwezoshishino, ukufezekisa ukutshintshiselana kwedatha yezixhobo.

Isekethe yojongano lwangasemva

Qhagamshela i-PLC rack ukuze uqaphele ukunikezelwa kwamandla kunye nokuhanjiswa kwedatha phakathi kweemodyuli.

Iisekethe zolawulo lwamandla

Ukuguqulwa kunye nokukhuselwa kwamandla okufaka, qinisekisa isiphaluka sangaphakathi kunye nokusebenza okuzinzile.

Iisekethe zokuxilonga kunye nezikhuselayo

Ubume bokusebenza bubekwe esweni ngumqondiso wesimo kunye nomsebenzi wokuxilongwa kwempazamo unikezelwa.

FAQ

Q1. Ngaba ukubuyisela umqhubekekisi kufuna ukubhala inkqubo kwakhona?

Ngokuqhelekileyo akunjalo. Ukuba kukho ugcino olukhoyo lwenkqubo ye-PLC yoqobo, khuphela ngokulula inkqubo kwaye uqinisekise unxibelelwano kunye noqwalaselo lwe-I/O.

Q2. Ndingatsho njani ukuba iprosesa iqhelekile?

Isalathisi sesimo se-CPU

Imeko yonxibelelwano ye-PLC

Ubume boMsebenzi weNkqubo

I/O impendulo

Q3. Ngaba ifanelekile ukugcinwa kwenkqubo ye-PLC endala?

Ifanelekile. Imodyuli ingasetyenziswa njenge-PLC - iinxalenye ezi-5 zokugcinwa kwenkqubo, ukunceda amashishini ukunciphisa iindleko zokuphucula kunye nokwandisa umjikelo wobomi bezixhobo ezizenzekelayo.

Q4. Bubude obungakanani ubomi bayo benkonzo?

Le modyuli yinkqubo ye-PLC yodidi lweshishini. Phantsi kokusingqongileyo okuzinzileyo kunye neemeko ezifanelekileyo zokugcinwa kakuhle: malunga neminyaka eyi-10 okanye ngaphezulu

Iimeko ezifanelekileyo zokulondolozwa: zinokusebenza ixesha elide

Izinto ezichaphazelayo:

Ubushushu bokusebenza

Uzinzo lwamandla

Umthwalo osebenzayo

Isidanga songcoliseko lokusingqongileyo

Imeko yogcino lwemihla ngemihla

Amatyala okwenene kunye novavanyo lwabathengi

Isixhobo senkqubo eqhubekayo yeshishini lemichiza samkelwe uyilo lwebhasi ye-ControlNet, kusetyenziswa i-Allen Bradley 1785 L46C15 njengomlawuli oyintloko. Ukuguga kwemodyuli kubangele umngcipheko wokungahambi kakuhle kwememori, kwaye kwakunzima ukufumana unikezelo oluthembekileyo lwasekuqaleni kwimarike. Sibonelele ngeentsimbi ezihlolwe ngokupheleleyo, kwaye umthengi ungenise ngokuthe ngqo inkqubo ekhuselweyo. I-ControlNet kunye ne-DH + inethiwekhi yachithwa ngempumelelo kanye, kwaye izixhobo zokuvelisa zaqala ukusebenza ngokuqhubekayo, ukuphepha ukulahlekelwa kwexesha elide.

Injineli yeChemical automation: Azikho ezininzi ii-CPU ze-1785 L46C15 ControlNet ezinememori ekhuselweyo kwimarike. Emva kokufumana imodyuli, uvavanyo lwesiteshi esigcweleyo lwaluqhelekile, kwaye umsebenzi wememori yokukhusela wawulungile. Kwakungekho mfuneko yokuguqula inkqubo yokuqala, ukunciphisa inani lomsebenzi wokulungisa.

Isiqinisekiso seNkampani

Xa kuthengwa iiprosesa eziyekiweyo, ngaba uyesaba iibhloko ezimbi kwimemori kunye nokungaphumeleli kwemisebenzi yokukhusela? Inkampani yethu iqhuba iziqinisekiso ezintathu kwi-1785 L46C15 nganye ngaphambi kokuba ithunyelwe: I-48K imemori epheleleyo yedilesi yokufunda nokubhala uvavanyo, ukuqinisekiswa komatshini wokwenene womsebenzi wokukhusela imemori, kunye novavanyo lozinzo lonxibelelwano lwe-ControlNet. Oku kuqinisekisa inkumbulo elungileyo, ukhuseleko oluthembekileyo, kunye nonxibelelwano oluzinzileyo.

Umthombo weemveliso zangempela unokulandelelwa, iingxaki zomgangatho ngaphakathi kwexesha lewaranti yokutshintshwa ngokuthe ngqo, iinjineli zobugcisa ukubonelela ngokutshintshwa kweprogram yamahhala kunye nesikhokelo sothungelwano.

Khetha kubaboneleli, ukuveliswa kweendawo ezisecaleni nazo zinesiqinisekiso sobungcali.
