Allen Bradley 1785 L20C15

I-Allen Bradley 1785 L20C15 iza kunye ne-interface yonxibelelwano eyakhelweyo kwaye iyahambelana ne-1771 series I / O rack. Ukusebenza kwayo okunengqiqo kunye namandla okusebenza kwedatha ihlangabezana neemfuno zolawulo lwezixhobo ezincinci kunye neziphakathi, kwaye ifanelekile kwiimeko ezifana nezixhobo zokupakisha, imigca yendibano encinci, kunye nezixhobo ezincedisayo zetsimbi. Njengomthengisi oqeqeshiweyo, i-Feimu Technology iya kugqiba iimvavanyo eziquka konke okuquka amandla onxibelelwano kunye nokuguga kwexesha elide kuwo onke amalungu angenayo angenayo, esusa iingxaki ezifihlakeleyo zokuguga zamalungu. Iimodyuli zinokuhambelana ngokuthe ngqo neenkqubo zeprojekthi yokuqala, kwaye ukuguqulwa kwendawo kunye nokuguqulwa kuncinci, ukunciphisa iindleko zokulungiswa kwezixhobo.

Ulwakhiwo lwangaphakathi

I-Allen Bradley 1785 L20C15, njengemodyuli yeprosesa yoluhlu lwe-PLC-5, ikakhulu yenziwe ngamacandelo alandelayo ngaphakathi:

Ibhodi yoLawulo ePhambili (PCB)

Iprosesa edibeneyo, imemori, kunye neesekethe zokulawula, ezinoxanduva lokwenziwa kweprogram kunye nokucubungula idatha.

Iyunithi yomqhubekisi (CPU)

Ukuqhuba inkqubo yokulawula ye-PLC, gqibezela umsebenzi wokuqiqa, ukusetyenzwa kwedatha kunye nolawulo lwenkqubo.

Iyunithi yokugcina (Inkumbulo)

Isetyenziselwa ukugcina iinkqubo zomsebenzisi, iitafile zedatha, kunye nenkqubo eqhuba idatha.

ISekethe yoNxibelelwano (iSekethe yoNxibelelwano)

Inoxanduva lokunxibelelana kwedatha phakathi kweprosesa kunye nezixhobo zangaphandle ezifana ne-DH + kunye ne-Remote I / O.

Ujongano olungasemva (Ujongano ngasemva)

Qhagamshelana ne-PLC-5 isakhelo ukunika amandla kwimodyuli kwaye uqaphele ukutshintshiselana kwedatha yangaphakathi.

Isimo sesekethe yesalathiso (Izalathi zesimo)

Ukusebenza kweprosesa, ukungaphumeleli kunye nesimo sonxibelelwano kuboniswa yi-LED.

Ubudlelwane bolwakhiwo: CPU → Inkumbulo → Ulawulo lwesekethe → ujongano lonxibelelwano → ujongano lweplane engasemva → inkqubo yePLC-5

Eyona ndawo yokuthengisa inzuzo

Ukuhambelana koyilo lwe-PLC-5: Ifanelekile ukugcinwa kwenkqubo ye-PLC-5 ekhoyo.

Ukusebenza kokulawula okuzinzileyo: ukuhlangabezana neemfuno zokusebenza okuqhubekayo kwezixhobo zoshishino.

I/O amandla okulawula: ixhasa ukuqokelela idatha kunye nokulawulwa kwezixhobo zentsimi.

Ukulungeleka kokugcinwa kwenkqubo: ingasetyenziselwa ukutshintshwa kweendawo ezisecaleni emva kokusilela kweprosesa yokuqala.

Inkxaso yoMjikelo woBomi: Inceda ukwandisa ixesha lokusetyenziswa kwezixhobo ze-PLC-5 zendabuko.

Iinkcazo zobuGcisa

Iinkalo zesicelo

I-Allen Bradley 1785 L20C15 isetyenziswa ikakhulu:

Imigca yemveliso ezenzekelayo kwimizi-mveliso,

Ulawulo lwezixhobo zoomatshini,

Iinkqubo zokuhanjiswa kwezinto,

Isixhobo sokulawula inkqubo,

Ukugcinwa kweenkqubo ze-PLC-5 zefektri,

Ukulungiswa kwezixhobo ezindala ezizisebenzelayo;

Imeko eqhelekileyo: Isetyenziselwa ukubuyisela iprosesa engalunganga kwinkqubo yokuqala ye-PLC-5, ibuyisela ukusebenza kwesixhobo ngelixa igcina uyilo lolawulo lokuqala.

FAQ

Q1. Uyicombulula njani ingxaki ukuba imodyuli iyasilela ukuqala?

Jonga i-PLC rack unikezelo lwamandla kunye nokufakela urhulumente, imodyuli ye-CPU kunye nesimo seprogram, qinisekisa ukuba kukho ukusilela kweprosesa.

Q2. I-PLC ayikwazi ukunxibelelana nemodyuli?

Khangela umgca we-DH +, idilesi ye-node, umqhubi wonxibelelwano kunye nokucwangciswa kwenethiwekhi, kwaye usebenzise i-RSLinx yokuxilongwa konxibelelwano.

Q3. Buyisela imfuno yangaphambili yogcino?

Kunconywa ukuxhasa iinkqubo ze-PLC, iifayile zedatha, uqwalaselo lwe-I / O kunye neeparitha zonxibelelwano kwangaphambili.

Q4. Ukuqinisekisa njani ukuba imodyuli isebenza kakuhle?

Qinisekisa ngokuhlolwa okubonakalayo, uvavanyo lokusebenzisa amandla, uvavanyo lokusebenza lwe-CPU, uvavanyo lonxibelelwano, kunye ne-RSLogix 5 inkqubo yokufunda / ukubhala uvavanyo.

Kutheni ukhethe thina

I-Feimu Technology iye yazibandakanya ngokunzulu ekungeniseni nasekuboneleleni iinxalenye eziyekiweyo zolawulo lwamashishini iminyaka emininzi. Sisebenzisa iifoto zokwenyani zeemveliso njengesiseko sokuthunyelwa kwaye siyala ukusebenzisa imifanekiso yobuxoki evela kwi-intanethi. Oko abathengi bakubonayo koko kanye bakufumanayo.

Kwii-CPU eziyekiweyo nezinqabileyo ezifana no-Allen Bradley 1785 L20C15, siye saseka isikhululo sokuhlola izixhobo ezizimeleyo. Imodyuli nganye igcinwa ngeefoto zokwenyani zemveliso, imifanekiso-skrini yovavanyo lonxibelelwano lwe-ControlNet, kunye nedatha yokusebenza ngokuguga. Iseti yonke yeerekhodi zokuhlola kunye neevawutsha zinokuboniswa ngabathengi.

Sibambelela ngokungqongqo ekungahlaziyini okanye ekutshintsheni iileyibhile zehardware, kwaye siyazise ngenyaniso imeko yemveliso. Sikwabonelela ngeenjineli zobugcisa boshishino oluzenzekelayo ukuncedisa ekuqinisekiseni ukuhambelana kwemodeli kunye nomgca wemveliso okhoyo ngaphambi kokubeka umyalelo. Iiodolo ezingxamisekileyo zixhasa ukuqinisekiswa kwevidiyo okude kweempahla kunye nokuthunyelwa okuphambili. Ukusuka kwimodeli yokuqinisekisa, ukuqinisekiswa kweempahla ukuya kuncedo lobugcisa kamva, sibonelela ngenkonzo epheleleyo yekhonkco ukunceda iifektri ziphephe ilahleko ebangelwe ngamalungu ahlaziyiweyo kunye neziphene ezifihliweyo kwintengiso yeengxenye eziyekiweyo.
