Allen Bradley 1769 IF16V

U-Allen Bradley 1769 IF16V yimodyuli ye-analog yohlobo lwe-16-channel voltage-type, esetyenziselwa ukuqokelela iisignali ze-sensor voltage kwaye isetyenziswa ngokubanzi kwizixhobo ezizisebenzelayo ezikhoyo kushishino lweekhemikhali zaphesheya, ukucocwa kwamanzi, ukwenziwa kwezinto, njl. ikwahluza iimveliso ngophawu lwe-drift kwaye yenza ulungiso lwehardware okanye uhlaziyo kwizinto ezineziphene. Nje ukuba iimveliso zifikile, zinokufakelwa ngokuthe ngqo kwisixhobo ukuze zitshintshwe, ngaloo ndlela zikhawulelana neemfuno ezingxamisekileyo zokulondolozwa kweefektri zaphesheya kweelwandle.

Inkqubo yokuFakela

1. Ukuqinisekiswa kwenkqubo → Qinisekisa ukuba i-Allen Bradley 1769 IF16V ihambelana nenkqubo yeCompactLogix 1769 kwaye umlawuli uyayixhasa le modyuli.
2. Nciphisa umbane → Cima iPLC kunye ne-I/O amandla enkqubo ukunqanda umonakalo wesixhobo owenziwe kufakelo oluphilayo.

3. Misela indawo yofakelo → Ngokwesicwangciso soqwalaselo lwe-I/O, faka imodyuli kwindawo echongiweyo yeqela lemodyuli ye-1769 I/O.

4.Ufakelo lwemodyuli → Lungelelanisa isiqhagamshelo sebhasi ye-1769, faka imodyuli kwaye utshixe iqhosha ukuqinisekisa ukuba imodyuli izinzile.
5. I-wiring yesignali yokudibanisa i-analog voltage input signal ngokwenkcazo ye-terminal, kwaye uqinisekise ukukhuselwa kwesignali kunye nokumisa phantsi kuchanekile.
6. Uqwalaselo lweSoftware → Yongeza i-1769-IF16V kwi-RSLogix 5000 / Studio 5000, kwaye usete uluhlu lwegalelo, iiparamitha zokucoca kunye nokucwangciswa kwesiteshi.
7. Amandla kuvavanyo → Buyisela unikezelo lwamandla enkqubo, jonga isalathisi semodyuli yokukhanya kunye nolwazi lokuxilongwa komlawuli.
8. Isiginali kwaye ujonge isignali ye-voltage yegalelo eliqhelekileyo, qinisekisa ukuba ixabiso lokufunda i-PLC lihambelana negalelo langempela, ukugqiba ukulungisa.

Amandla angundoqo

Igalelo le-16 ye-channel high-density: imodyuli enye inokuqokelela i-multichannel analog voltage signal, ukulawula indawo yekhabhinethi yokulondoloza.
Ukuguqulwa kwesignali echanekileyo ephezulu: i-Sigma - Delta A / D yokuguqula iteknoloji, iphucula ukuzinza kokufunyanwa kwedatha.
Inkxaso yoluhlu lwamandla amaninzi: ilungele iintlobo ezahlukeneyo zenzwa kunye nezixhobo zentsimi.
Ikhono elinamandla lokuchasana nokuphazamiseka: ukuxhasa igalelo lokucoca kunye nemisebenzi yokuxilongwa, ukuphucula ukuthembeka kwendawo yoshishino.
Ukulungelelaniswa kweCompactLogix: Ukufikelela ngokuthe ngqo kwi-1769 ye-I / O inkqubo, ukuyila inkqubo elula.

Iiparamitha ezibalulekileyo

Kutheni ukhethe thina

ITekhnoloji yeFeimu ibonelela ngeendawo ezinqabileyo zolawulo lwamashishini eziye zayekiswa eRockwell kwihlabathi liphela. Ikhusela ngokungqongqo imithombo yokubonelela ye-Allen Bradley 1769 IF16V imodyuli ye-analog ye-analog kwaye ishenxisa ukulungiswa kunye nokulungiswa kwamalungu ngokunciphisa okuchanekileyo kunye neempazamo zetshaneli. Ngaphambi kokuba imodyuli nganye ikhutshwe kwindawo yokugcina izinto, ukuqinisekiswa ngokuchanekileyo kwamajelo amaninzi kunye nokuhlolwa kwe-intanethi ye-backplane kugqityiwe ukuphepha iimpazamo ezifihliweyo ezifana ne-analog drift kunye nokufunda okungachanekanga, kunye neerekhodi zovavanyo zikhutshwa. Ukuxhasa iintlobo ngeentlobo zolungiselelo lwamazwe ngamazwe, unokugqiba iseti epheleleyo yamaxwebhu esibhengezo samasiko orhwebo lwangaphandle. Ukuqhelana nokugcinwa kweCompact phesheya (I / O kunye nezixhobo ezindala, zinokubonelela ngesiseko soncedo lobugcisa, ngokukhawuleza ukusetyenzwa kwe-analog ukufumana iingxaki ezingaqhelekanga, ukunciphisa ixesha lokuphumla elingacwangciswanga lizisa ilahleko yemveliso.

Iinkalo zesicelo

1. Ulawulo lweNkqubo yoShishino

Ukuqokelela imiqondiso yamandla ombane ukusuka kuxinzelelo, ubushushu, inqanaba lolwelo kunye nezinye ii-transmitter;

Isetyenziselwa ukujonga ngexesha lokwenyani inkqubo yemveliso.

2. Imigca yemveliso ezenzekelayo

Ukufumana ingxelo ye-analog yesivamvo;

Qonda ukufunyanwa kwemeko yezixhobo kunye nolawulo oluvaliweyo.

3. Inkqubo yokubeka iliso kwezixhobo

Imoto yokubeka iliso, unikezelo lwamandla, iiparamitha zokulinganisa ukungcangcazela, ezifana;

Ukuphucula ukusebenza kakuhle kogcino lwezixhobo.

4. Inkqubo yolawulo lwamandla

Ukuqokelela amandla ombane kunye nemiqondiso ye-analog ehambelana namandla;

Isetyenziselwa uhlalutyo lwedatha kunye nolawulo lokuphucula.

5. Izixhobo zokwenziwa koomatshini

Isetyenziselwa i-CNC, i-robot, izixhobo zokuvavanya kunye nokunye ukufumana ubuninzi be-analog.

Ityala lomthengi kunye novavanyo

Imodyuli ye-1769 IF16V yesityalo sokucoca amanzi aphesheya ine-channel yokufunda i-drift, ukuphazamiseka kwedatha yenzwa, kunye neeparitha zenkqubo azikwazi ukulawulwa ngokuqhelekileyo. Umthengi uthenge imodyuli yoqobo esemgangathweni evela kwiTekhnoloji yeFeimu, kwaye ukuhanjiswa komda kwagqitywa ukutshintshwa. Yonke ishaneli ye-analog iqokelele idatha yafumana ukuchaneka kunye nokuzinza, kwaye izixhobo zaphinda zaqala ukusebenza okuqhelekileyo.

UVavanyo loMthengi: Akulula ukufumana imodyuli yobungakanani be-analog yezempilo. Ukuyifumana ngokuthe ngqo kufakelo kusonjululwe ingxaki enzima yokukhukuliseka kwedatha kuthi.

FAQ

Q1. Zinokuba ziziphi izizathu zophawu longeniso olungazinzanga?

Umgca wesignali ye-analog awusebenzisi ucingo olukhuselekileyo;

Umgangatho ophantsi;

Uqwalaselo loluhlu lwegalelo olungachanekanga;

Uphazamiseko lombane oluvela kwiimotor, iiconverter frequency, njl. lukhona kwisiza;

Isiphumo soluvo aluzinzanga.

Q2. Uyiphatha njani i-PLC ukungakwazi ukuqaphela?

Ngaba i-Allen Bradley 1769 IF16V ifakwe ngokuchanekileyo;

Ngaba uqhagamshelo lwebhasi ye-1769 luqhelekileyo;

Ngaba uqwalaselo lwemodyuli kwiStudio 5000 / RSLogix 5000 ichanekile;

Ngaba i-firmware yomlawuli iyahambelana.

Q3. Indlela yokuphucula ukuchaneka komlinganiselo?

Sebenzisa umthombo wesignali ozinzileyo kwisiza;

Seta ngokuchanekileyo uluhlu lwegalelo;

Seta ngokufanelekileyo igalelo lokucoca iparameters;

Yenza umsebenzi omhle ekukhuseleni umgca wesignali kunye nokumisa.

Q4. Zeziphi izixhobo ezinokuqhagamshelwa?

Izixhobo zemizi-mveliso apho imiqondiso yombane wemveliso inokudityaniswa khona, umzekelo:

Inzwa yoxinzelelo;

Uluvo lwenqanaba lolwelo

Isidlulisi sobushushu;

Uluvo lwendawo;

Isixhobo sokulinganisa.

Q5. Zeziphi iimpazamo eziqhelekileyo?

Akukho mqondiso wegalelo kwitshaneli;

Ukutenxa okukhulu kumaxabiso okufunda;

ukuguquguquka kwexabiso legalelo;

Ukusilela konxibelelwano lwemodyuli;

Impazamo yoqwalaselo lwesitishi.
