I-GE Fanuc IC693ALG220

I-GE Fanuc IC693ALG220 yimodyuli ye-analog yohlobo lwe-4-channel voltage elungiselelwe ngokukodwa i-Series 90-30 PLC. Ixhotyiswe ngeyunithi yokuguqulwa kwe-analog-to-digital ephezulu ye-12 kunye ne-17Hz yokucoca i-hardware, eyenza le modyuli iqokelele ngokuchanekileyo i-analog voltage kunye neempawu zangoku ezivela kwiindawo zoshishino.

Le modyuli inezibonelelo ezinje ngokuchaneka okuphezulu, uzinzo oluphezulu, kunye nobuchule obunamandla bokuchasana nokuphazamiseka. Ezi mpawu ziyenza isetyenziswe ngokubanzi kwiimeko ezifana nobunjineli beekhemikhali, oomatshini, i-HVAC, kunye nemigca yemveliso ezenzekelayo, ekwazi ukuqokelela ngokuchanekileyo imiqondiso eyahlukeneyo ye-analog yemveliso efana noxinzelelo, inqanaba lolwelo, ubushushu, ukufuduka, kunye nempendulo rhoqo, kunye nokuhlangabezana neemfuno zokubeka iliso kwiinkqubo ezininzi ezincinci kunye neziphakathi.

Ukuba ufuna isisombululo esiqolileyo nesithembekileyo sokufumana isisombululo se-analog yeshishini, nceda uqhagamshelane neFeimu Technology. Sinempahla ekhoyo kwaye sinokukunika yona.

Iinzuzo zemveliso

I-GE Fanuc IC693ALG220, njengemodyuli ye-analog yohlobo lwe-4-channel voltage, inezi nzuzo zilandelayo:

1. Ukuzinza okuphezulu: Iquka i-1500VAC yodwa yombane, ukuxhathisa ngokufanelekileyo i-loops yomhlaba kunye nokuphazamiseka kokunyuka; ihambelana ne-EMC yoshishino kunye nemigangatho ye-seismic, ixhasa ukusebenza kobushushu obubanzi, kwaye ifanele indawo yezoshishino ezinzima kunye nezinzima.

2. Ukuhambelana okubanzi: Ixhotywe nge-12-bit ye-ADC yokuguqulwa kwe-analog-to-digital echanekileyo, ine-filtering ye-hardware eyakhelwe ngaphakathi, iyamelana nokuphazamiseka kwe-high-frequency, kwaye inomgca obalaseleyo; ixhasa -10V ukuya + 10V iimpawu zombane, kwaye i-resistor yangaphandle inokuhambelana ne-4-20mA i-universal transmitters, ifanelekile kwiimeko ezininzi zokufumana ubuninzi be-analog yezoshishino.

3. Akukho maxhala ngokutshintshwa: Inamaxwebhu obugcisa atyebileyo kunye neemeko zezicelo, ezilungele ukulungiswa kwezixhobo ezidala, uhlaziyo lwesistim, kunye neemeko zokutshintshwa kwee-spare parts, ezinepraktikhali eyomeleleyo ngokugqithisileyo.

4. Ukuhambelana okuphezulu: Ihambelana ne-GE 90-30 series PLCs, ene-footprint encinci kwi-slot, ukulinganisa kwefektri kukhululekile, iprogram kunye ne-wiring ilula, kwaye inokukhawuleza isetyenziswe.

Iinkalo zesicelo

Kwiindawo zoshishino, ukufunyanwa kwe-sensor ye-analog ye-sensor eyahlukeneyo kusetyenziswa ngokubanzi kwiinkalo ezifana nezixhobo zoomatshini, ubunjineli beekhemikhali, unyango lwamanzi, i-HVAC, izixhobo zakudala ze-metallurgical, kunye nemigca yokuvelisa ezenzekelayo.

Iyakwazi ukuqokelela iimpawu ukusuka kuxinzelelo, umgangatho wolwelo, ubushushu, ukufuduswa, izinga lokuqukuqela, njl njl. ii-transmitter, kwaye inokufumana kwakhona iimpawu ze-analog voltage ukusuka kwi-10V ukuya kwi-10V ukusuka kwi-converter frequency kunye ne-potentiometers. Isetyenziswa ngokubanzi ekubekweni esweni kwesimo sezixhobo, ukuqokelelwa kwedatha, inkqubo yokubeka iliso kwiparamitha, kunye nokuhlaziya iiprojekthi zeenkqubo ezizisebenzelayo zakudala kwiindawo ezisecaleni ze-GE Fanuc IC693ALG220.

Itekhnoloji / Inkqubo

I-GE Fanuc IC693ALG220 yenziwe kusetyenziswa ubugcisa bekhadi lebhodi yeshishini. Isebenzisa i-PCB enemigangatho emininzi enokumelana namaqondo obushushu aphezulu naphantsi, ene-wiring eyahlukileyo ye-analog kunye ne-digital circuits kunye ne-three-layer anti-corrosion coating. Ikhetha i-drift ephantsi yobushushu kunye nezinto ezichanekileyo eziphezulu, ixhotyiswe ngeesekethe zokucoca i-hardware, kwaye igqibe i-zero-point kwaye izuze ukulinganisa kumzi-mveliso.

Ixhotyiswe ngesixhobo sokuzihlukanisa se-1500VAC ukufezekisa ukuhlukaniswa phakathi kwecala lomqondiso kunye necala lengqiqo. Ikwadityaniswe nezibambiso ezomeleziweyo kunye neetheminali zokucinezela izikrufu zokumelana nokothuka kunye nokuchasana nokukhulula. Lo matshini uphela wenze iimvavanyo ezininzi zasefektri kubandakanya ukuhamba ngebhayisikile ephezulu kunye nesezantsi, ukumelana noxinzelelo, ukuchaneka, kunye ne-EMC.

Le mveliso iyimodeli eyekiweyo kwaye ayinayo itekhnoloji yale mihla yoxinaniso oluphezulu. Ukufunyaniswa komqondiso wangoku kufuna i-250Ωresistor yangaphandle.

Iiparamitha

Yintoni eyenziwa nguFeimu

I-Feimu Technology ayithumeli iimodyuli ezingavavanywanga. I-IC693ALG220 nganye ihamba ngale nkqubo ilandelayo yokuqinisekisa phambi kokuba siyishiye indawo yethu yokugcina impahla.

Uhlolo olubonakalayo: Umbala wephaneli ukhangelwe. Iileyibhile ziqinisekisiwe. Izikrufu zebhloko yetheminali zihlolwe ukusebenza kakuhle.

Uvavanyo lwamandla: Imodyuli efakwe kwi-Series 90-30 test chassis. Imodyuli yamkelwa yiPLC.

Uvavanyo lwesitishi: Zonke iziteshi ezi-4 zivavanywe nge-± 10V iimpawu zombane. Ufundo luqinisekisiwe ukuchaneka.

Uvavanyo lokuzihlukanisa: I-1500VAC yodwa phakathi kwecala lentsimi kunye necala lengqiqo liqinisekisiwe.

Uvavanyo lwe-LED: Imodyuli yemodyuli ye-LED ihlolwe ukusebenza ngokuchanekileyo.

Ukupakishwa: Imodyuli efakwe kwi-anti-static bag. Itywinwe kwibhokisi ene-foam. Ilebhile ngenombolo yemodyuli kunye nomhla wovavanyo.

FAQ

I-Q1: Yintoni iqondo lokushisa elisebenzayo? Ngaba inokusetyenziswa kwikhabhinethi yobushushu obuphezulu?

Ubushushu bokusebenza: 25℃~+70℃. Ubushushu bangaphakathi kwikhabhinethi akufuneki budlule kwi-70℃. Ukushisa okugqithisileyo kuya kubangela ukuhla kwesampulu echanekileyo.

I-Q2: Ngaba iziteshi zodwa komnye nomnye?

Akukho mahluko phakathi kwamajelo. Kuphela icala lomqondiso wentsimi kunye necala le-logic yebhodi ye-PLC ine-1500VAC yodwa. Iitshaneli ezininzi zabelana ngetheminali ye-COM eqhelekileyo.

Q3: Ngaba iimodyuli zifuna i-hardware setting jumpers?

I-IC693ALG220 ayinayo i-hardware jumpers. I-voltage kunye neendlela zangoku zifezekiswa ngokupheleleyo nge-wiring yangaphandle kunye ne-resistors yangaphandle. Umzimba wemodyuli awunalo iswitshi yediphu.

I-Q4: Ziphathwa njani izaleko ezikhuselayo zee-transmitter ezininzi? Ngaba kufuneka zisekelwe kuzo zombini iziphelo okanye kwinqanaba elinye?

Kwiintambo ze-analog ezikhuselekileyo, kuyacetyiswa ukuba zibekwe phantsi kwelinye icala. Umaleko okhuselayo kufuneka ubekwe kuphela kwicala lokuhambisa, kwaye umaleko okhuselayo kwicala lemodyuli kufuneka ushiywe udada. Ukuthoba kuzo zombini iziphelo ngokulula kwenza iluphu yomhlaba, ebangela ukukhukuliseka kunye nokuguquguquka kwamaxabiso.

Kutheni ukhetha thina?

Sineseti epheleleyo yeenkqubo zovavanyo zobuchwephesha kunye nezibanzi, siqinisekisa ukuba iimveliso zethu zisemgangathweni kwaye zikumgangatho obalaseleyo. Sizimisele ukubonelela abathengi ngezona zisombululo zilungileyo kwiingxaki zabo kunye nokubonelela ngeyona nkonzo iphezulu emva kokuthengisa.
